• Design Wheel/Tire Sizes29 x 3.0″
• Max Tire Outer Diameter29 x 3.0″ (Different tire and rim combinations will result in different clearances. Depending on drivetrain configuration, tire clearance may be limited by the chain and not the frame. For suspension fork tire clearance, please reference the fork manufacturer’s website.)
• Frame Construction4130 Chromoly, Natch tubing, double-butted main triangle, trumpet flared tubes, TIG welded, ED coated
• Fork Construction4130 Chromoly, Natch tubing, double-butted tapered fork blades, TIG welded, ED coated
• Suspension Fork Length (Travel)Max. Suspension fork length: 550 x 51mm (29+ 120mm) (Suspension fork length listed at full extension, not at sag)
• Rigid Fork Length483mm
• Fork Offset47mm
• Axle to Crown483mm
• Rear Spacing“Gnot-Boost” 145mm; 12 x 142mm or 12 x 148mm (Surly axle included) / 10 x 135mm with Surly 10/12 Adapter Washers (not included)
• Rear Brake (Rotor)Disc – 51mm I.S. (203mm max rotor)
• Front Brake (Rotor)Disc – 51mm I.S. (203mm max rotor)
• Headset – UpperZS44/28.6
• Headset – LowerEC44/30
• Front Spacing15 x 110mm
• Steerer TubeØ28.6mm (1-1/8″)
• Crown RaceØ30mm (1-1/8″)
• Stem ClampØ28.6mm (1-1/8″)
• SeatpostØ30.9mm
• Dropper Post CompatibleYes
• Seatpost ClampØ33.1mm
• Front Derailleur Clamp(Ø34.9mm)
• Front Derailleur TypeHigh direct mount top-pull (Ø34.9mm); 26mm offset adapter (not included) for 142 or 135mm rear hub spacing; 29mm offset adapter (not included) for 148mm rear hub spacing
• Bottom Bracket73mm threaded (1.37″ x 24TPI)
• Crankset (Max Ring)1x (Mtn): 28T / 1x (Boost): 30T / 2x (Boost): 24/36T (Listed chainring clearance is worst-case scenario. Clearances vary widely depending on components and configurations)
• Bottle Mounts1 Standard + 1 Three-Pack
• Rear Fender MountsYes

※製品仕様は予告なく変更される場合があります。
