ECR 27.5+

  • Beige Pantsuit
ECR 27.5+
税込¥121,000 (生産終了。在庫のみ)
XS, S, M
Beige Pantsuit
※BEIGE PANTSUITは、本国生産終了につき、弊社在庫限りで終了となります。※2019ニューカラーフレームの情報は、こちらをご覧ください。
Tubing Surly 4130 CroMoly steel. Custom double-butted trumpet tube main triangle. TIG-welded. ED coated
Rear Dropouts Horizontal slotted with derailleur hanger; Surly Gnot-Boost 135, 142, or 148mm hub spacing compatibility, Features Rohloff torque arm slot and threaded eyelets for fenders, racks and Surly trailer mounts
Brake Compatibility 51mm I.S. disc calipers (Max rotor size 160mm rear with Surly brake adapter, 203mm front)
Braze-ons/extras XS, S, M (27.5+) has two triple bottle-mounts. Surly Trip Guide full line guides for brake and derailleurs, fender and rack eyelets
Seatpost diameter 27.2mm
Seatpost clamp diameter 30.0mm (Surly stainless included)
Headset/Steerer Tube 1-1/8″ threadless
Front Derailleur Clamp Diameter 28.6mm, High direct-mount standard, clamp adapter included
Bottom bracket shell 73mm shell width, threaded standard English (1.37″ x 24t)
Chainring Clearance Triple 22/34/44t, Double 26/39t, Max single ring clearance, middle position, 34t. Outer position 44t. (Triple will only work with 2.5″ tires or smaller)
Tire Clearance 27.5+ is 27.5 x 3.0″ (with fenders); Individual tire and rim combos affect tire clearance
Fork TIG-welded custom-butted 4130 CroMoly, non-suspension corrected, 1-1/8″ steerer tube, 203mm disc brake clearance
Thru Axle HU0134 Surly 12×142/148 Rear Thru Axle
Color Beige Pantsuit
  XS S  M
Seat Tube Length(Center-Top) 346.4 406.4 457.2
Top Tube Length(Center-Center) 536.3 547 563.1
Effective Top Tube Length(Center-Center) 555 575 595
Head Tube Angle 69 69 69
Seat Tube Angle 73 73 73
BB Drop 60 60 60
Chainstay Length 435 435 435
Wheelbase 1052.3 1074 1096
Standover Height 726 766 802
Head Tube Length 90 115 140
Fork Length 447 447 447
Stack 556 579.5 603
Reach 385 398 410.5
